sh380 Skid-steer loader

HX380 Wheel Loader – Compact Power for Light-Duty Jobs

The HX380 is a compact wheel loader engineered for landscaping, farming, and light construction applications. With its powerful engine, compact dimensions, and reliable hydraulic system, this machine delivers efficient performance in tight spaces.

Key Features

Powerful Engine
Equipped with a 24 HP R740D twin-cylinder diesel engine with mechanical speed control, delivering reliable power at 3600 rpm. EPA-compliant with 739.3 cc displacement and natural aspiration.

Compact Dimensions

Overall length with bucket: 2321 mm

Width: 1130 mm

Height: 1280 mm

Operating weight: 780 kg

Working Performance

Rated load: 280 kg

Bucket capacity: 0.08 m³

Maximum digging force: 458 kN

Travel speed: 0-5.5 km/h

Three-function cycle time: 8.5 s

Hydraulic System

System pressure: 170 bar

PARKER hydraulic pump

Songheng BMER-375 gear motor

Northern Hydraulic multi-way valve

2 auxiliary outputs

Working Range

Maximum working height: 2540 mm

Maximum dumping height: 1430 mm

Dumping reach: 500 mm

Ground clearance: 105 mm

Wheelbase: 690 mm

Specifications

Specification Value
Engine Model R740D Mechanical Speed Control
Power 24 HP
Rated Speed 3600 rpm
Cylinders Twin cylinder
Displacement 739.3 cc
Emission Standard EPA
Rated Load 280 kg
Bucket Capacity 0.08 m³
Travel Speed 0-5.5 km/h
Fuel Tank Capacity 18 L
Tire Model 18×8.5-8
Operating Weight 780 kg
Overall Dimensions 2321×1130×1280 mm
Typical Applications

Landscaping and gardening

Small farm operations

Nursery material handling

Light construction tasks

Snow removal

Note: Manual measurements may vary. Please refer to actual machine for final specifications.

• Powerful Twin-Cylinder Engine
• Compact and Maneuverable Design
• High-Performance Hydraulic System
• Impressive Lifting Capacity
• Excellent Working Range
