The 230PC-9 is a heavy duty crawler excavator built for tough jobs. Powered by a Cummins 6BTAA5.9 or ISUZU 6BG1 engine, it delivers reliable performance with low fuel consumption.

Key Features

  • Operating Weight: 22.3 tons
  • Bucket Capacity: 1.2 m³
  • Engine Power: 128–135 kW
  • Max Digging Depth: 6,592 mm
  • Max Digging Reach: 9,873 mm
  • Max Digging Height: 9,616 mm
  • Travel Speed: 5.9 km/h (high) / 3.2 km/h (low)
  • Gradeability: 70%

Strong Undercarriage & Hydraulics

The machine comes with 600mm or 800mm track shoes (optional) and a sturdy undercarriage for excellent stability. Main pump, control valve, and swing motor are all Kawasaki components, while the travel motor is from Doosan – ensuring smooth and efficient operation.

Wide Application

The 230PC-9 is ideal for:

  • Earthmoving and excavation
  • Quarry and mining work
  • Road and bridge construction
  • Large foundation projects

Why Choose 230PC-9?

  • High digging force – 144.1 KN
  • Long boom (5.7m) and arm (2.9m) for extra reach
  • Comfortable cabin with good visibility
  • Easy to maintain and operate
